FT-1000 single layer stretch film machine / cling film machine
Produce double side sticky or double side non-sticky film
can produce stretch film, cling film
use
This machine uses LDPE and LLDPE to produce casting stretch film（could produce one-side sticky film and the other side normal）, adopting double screws and double two hoppers. This co-extrusion stretch film is widely used in packing area for architecture, auto parts, hardware parts,etc.
Characteristics
1. Screw and cylinder are all made of 38 CrMoALA after nitrogen treatment, which has an advantage of corrosion resistance and endurance, etc.
2. The cooling device adopts cycle water cooling which provide the best transparent effect of the stretch film
3. Rewinder adopts with friction-rewinding-type, with cutter device for edge correcting.
OPTIONAL EQUIPMENT
1.auto loader
2.auto dryer
3.electric screen net changer
4.hudraulic screen net changer
5.glue pump
6.aut cutter, auto changer, SIMENS PLC controller, air shaft roller
Main Technical Variables：
|
Model |
FT-1000 single-layer |
FT-1200 single-layer |
|
Diameter of Screw Stem |
75 mm |
75 mm |
|
L/D Ratio of Screw |
28:1 |
28:1 |
|
Material of Scerw & Barrel |
38 CrMoALA |
38 CrMoALA |
|
Rationl Speed of Screw Stem |
10-120 rpm |
10-120 rpm |
|
Width of T-die |
1250 mm |
1500 mm |
|
Heating Way |
Casting-aluminum heating device |
Casting-aluminum heating device |
|
Width of Traction Roller |
1250 mm |
1400 mm |
|
Folding Width of Products |
300-1000 mm |
1200 mm |
|
Thickness |
0.015-0.05 mm |
0.015-0.05 mm |
|
Main Motor |
30 kw |
30 kw |
|
Heating Power |
30 kw |
45 kw |
|
Tractiong Motor |
4 kw |
4 kw |
|
Max. Output（kg/h） |
100 |
120 |
|
Machine Weight |
4.5T |
5.5T |
|
Overall Dimensions (L*W*H) |
7500 mm*4000 mm*3200 mm |
8500 mm*4500 mm*4000 mm |
